DGStation AB IPBox 910HD Silver

Ännu en ny digitalmottagare baserad på Linux med nätverk som är HD Ready. CubeRevo Mini (även kallad IPBox 910HD) har stöd för HD-upplösning på upp till 1080i med HDMI-utgången på baksidan. Plats för inbyggd SATA-hårddisk finns men även möjlighet att koppla en extern via USB eller e-SATA. Skillnaden mellan denna modell och CubeRevo HD är att du enbart har två modulplatser, inga kortläsare samt att du endast har plats för en tuner.

• DVB compliant ,DVB-S2, DVB-S, DVB-T, DVB-C tuner module supported
• Smart tuner supported(Plug & Play)
• MPEG-2 MP@HL Video Decoder
• MPEG-4 AVC/H.264 HP@L4 Video Decoder
• 1 smartcard reader
• 2 CI slots
• possibility to install internal HDD
• DIVX supported
• Dolby digital decoder
• MP3 decoder
• HDMI with HDCP supported
• Multi-format Audio Decoder
• High Definition and Standard Definition
• DVB Common Interface (2 slot) supported
• Format resolution: 1080i, 720p, 576i
• USB 2.0(Host) supported
• Network Interface Supported( high speed Ethernet)
• SCPC and MCPC receivable from C/Ku-band satellites
• Channel list editing
• Favorite channel list editing
• True-color On-Screen Display (OSD)
• Full Picture In Graphic (PIG) function
• Electronic Program Guide (EPG) for on screen channel information
• Subtitle & Teletext supported
• Parental lock facility by channel and program event
• External e-SATA interface supported
• LINUX open source(some parts under the terms of GPL, accordingly expandable)
• Silver edition

• 	Type	Specifications
  CPU	Type	266MHz ST40-202 32bit RISC CPU
  	Data/Instruction Cache	32KB/16KB
  Satellite QPSK Tuner(DVB-S)	Input Connector	IEC 169-24 Female(F-type)
  	Input Signal Level	-65 to -25dBm
  	Frequency Range	950MHz to 2150MHz
  	LNB Control	Vertical		13V(400mA Max)
  		Horizontal		18V(400mA Max)
  	Waveform	QPSK(C/KU band compatible)
  	22KHz Tone	Frequency		22±4KHz
  		Amplitude		0.6±0.2V
  	Symbol Rate	QPSK( up to 45MS/s)
  	DiSEqC Control	Version 1.0/1.1/1.2/USALS Compatible
  Satellite 8PSK Tuner(DVB-S2)	Input Connector	IEC 169-24 Female(F-type)
  	Input Signal Level	-65 to -25dBm
  	Frequency Range	950MHz to 2150MHz
  	LNB Control	Vertical	13V(400mA Max)
  		Horizontal	18V(400mA Max)
  	Waveform	QPSK, 8PSK(C/KU band compatible)
  	22KHz Tone	Frequency	22±4KHz
  		Amplitude	0.6±0.2V
  	Symbol Rate	QPSK( up to 45MS/s),   DVB-S2 :QPSK(up to 36MS/S), 8PSK(up to 30MS/s)
  	DiSEqC Control	Version 1.0/1.1/1.2/USALS Compatible
  Terrestrial OFDM Tuner	Input Connector	IEC169-2 female
  	Loop through Connector	IEC169-2 male
  	Frequency Range	50MHz to 870MHz
  	Loop through Out Impedance	75 ohms nominal
  	Band Width	7/8 MHz
  	Carrier Mode	2k & 8k hierachical/non-hierachical mode
  	Constellation	Auto(QPSK, 16/64 QAM)
  	Mode Rate	Auto(1/2, 2/3, 3/4, 5/6 and 7/8)
  	Guard Interval	Auto(1/4, 1/8, 1/16 and 1/32)
  Cable QAM Tuner	Input Connector	IEC169-2 female
  	Loop through Connector	IEC169-2 male
  	Frequency Range	47MHz to 862MHz
  	Loop through Out Impedance	75 ohms nominal
  	IF Bandwidth	8MHz
  	QAM mode	16, 32, 64,128,256QAM
  	Symbol rate	0.87Mbaud~7Mbaud Max.
  MPEG Transport Stream    & A/V Decoding	Input Stream	ISO/IEC 13818-2,, H.264
  	Profile & Level	MPEG-2 MP@ML, MP@HL, MPEG4 AP@HL/H.264 level 4.1
  	Input TS Data Rate	138Mbit/S max.
  	Aspect Ratio	4:3, 16:9 with Pillarbox or LetterBox
  	Video Resolution	720 x 576(PAL), 1080i, 720P, 576i
  	Audio Decoding	MPEG-1 Audio Layer 1,2, Musicam
  	Audio Mode	Stereo, Dual Channel, Joint Stereo, Mono
  	Sample Rate	32, 44.1, and 48KHz
  Memory	Flash Memory	32MB
  	DDR SDRAM	192MB (64MB 128MB)
  Storage & Rear   connector	HDD	e-SATA(1.5Gbps) interface on rear panel
  	Digital interface for HDTV	HDMI with HDCP
  	SCART I/F	TV
  	CVBS & Audio R/L Out	RCA(3 Ports)
  	Component Out(YPbPr)	RCA(3 Ports)
  	Digital Audio	S/PDIF via Optical
  Data In/Out	USB Host Interface	USB A-Type Female (USB 2.0)
  	RS232C	9 Pin D-Sub
  Network	Ethernet	RJ-45( 100BT )
  Conditional Access	Common Interface	2 PCMCIA Common interface Slot
  Front Display	VFD	14 dot matrix
  Power Supply	Input Voltage	AC110-245V, 50/60Hz
  	Type	Linear PWM
  	Power Consumption	35W
  	Protection	- Separate Internal Fuse and Chassis - Grounding the input shall have lightning or Electric Shock Protection
  Physical Specification	Size (W x H x D)	300mm x 60mm x 240 mm
  	Weight	2.5Kg
  Environment	Operating Temperature	5 ~ 55°C
  	Storage Temperature	-40°C ~ 65°C
