Produktinformation
Storlek
Dimensioner [L x B x H] 260mm x 180mm x 57mm
Vikt ca 2,0 kg
Anslutningar
HDMI Ver. 1,2
1x SCART TV
RCA HD YUV (YPbPr) eller RGB
SD-Audio RCA x 2
Tuner IEC169, F-kontakt, hona
S / PDIF optisk
PVR USB 2.0
Network 10 / 100 Mbps
Audio / Video Decoder
Videoformat 4:3 & 16:9 [Letter Box, Pan & Scan]
Video Resolution 1080i, 720p, 576p, 576i (SCART)
Transport Stream ISO MPEG 2 / 4
Audio dekoder MPEG Audio Layer 1 & 2
Conditional Access System
1 plats Common Interface PCMCIA, DVB CI Standard
1 plats Smart Card
Conax CAS, XCrypt, DGCrypt, Crypton, Firecrypt
LNB Control
Polarization 13/18V (500mA max)
Amplitute 0,7 V + / - 0,1 V
DiSEqC 1.0, 1.1, 1.2, vanligt, UNICABLE
22 KHz tone + / - 4 KHz
Makt
Inspänning AC 90-250V 50Hz/60Hz
Strömförbrukning 29 W max
Enligt 3 watt standby
System
Flash-minne 8 MB
2 x 64 MB SDRAM
EEprom 32 KByte
VDRAM 1 x 64 MB SDRAM
STi7101 processor, 266 MHz
Tuner
Input Symbol Rate DVB-S: 2-45 MS / S
Input Symbol Rate DVB-S2: 10 till 31 MS / s [8PSK]
Signal Level -35 - -85 dBm
Frekvensområdet 950 MHz till 2150 MHz
